Airbus 340-200

Key Design Characteristics

1. Fuselage and Capacity (The "Shrink"):

• The A340 family launched with two models: the baseline A340-300 and the shorter A340-200.
• The A340-200 is the shortest variant of the entire A340 family. It is roughly 4.2 meters shorter than the A340-300.
• Seating: Because it is shorter, it has a lower passenger capacity. It typically seats around 240 to 260 passengers in a standard three-class configuration.

2. Range and Performance:

• The Trade-off: Similar to the relationship between the A330-200 and -300, the A340-200 used the "shrink" formula. By shortening the body (reducing weight and passenger count) but keeping the full fuel capacity of the larger -300, the -200 gained significant range.
• Range: It had a range of approximately 7,500 nautical miles (13,890 km). At the time of its launch, it was one of the longest-range commercial aircraft in the world, designed for very long routes with moderate passenger demand (long and thin routes).

3. Engines:

• The first generation A340s (both the -200 and -300) were powered by four CFM56-5C engines.
• A note on the engines: These engines were very reliable but were relatively small for such a large aircraft. As a result, the A340-200/300 had a reputation for a very slow rate of climb and a relatively slow cruising speed compared to competitors like the Boeing 747.

4. Cockpit Commonality:

• It features the exact same fly-by-wire cockpit as the A330 and A320 families. Pilots rated for the A330 only required minimal difference training to fly the A340-200.

Summary and Commercial Fate

The A340-200 was a technological success but a commercial failure.

It entered the market just as engine technology improved dramatically. Very quickly, twin-engine aircraft like the Boeing 777 received certification to fly the same long routes as the A340, but they did it burning vastly less fuel because they only had two engines instead of four.

The A340-200 became obsolete very quickly due to its high operating costs compared to new twin-jets. Only 28 of the A340-200 model were ever built before production ceased. Very few remain in service today, mostly serving as government or VIP transports.
